Blood Gas and pH Analyzer MD-BGP-1002 requires an ultra-low sample volume of 70 to 100 µL for accurate testing. Its high-speed analysis delivers results in 90 seconds or less, optimizing workflow efficiency in emergency and intensive care environments. The fully automated calibration system enhances accuracy while reducing maintenance efforts, ensuring consistent performance. Our product compact yet durable design makes it ideal for ICU, operating rooms, and diagnostic laboratories.
$ 5250 : Each of 1
Specifications
| Sample Volume | 70 to 100 µL (depending on selected tests) |
| Analysis Time | Less than or equal to 90 seconds |
| Display | 12.1-inch color LCD touchscreen |
| Measured Parameters | pH, pCO₂, pO₂, Na⁺, K⁺, Ca²⁺, Cl⁻, Hct, Glucose, Lactate |
| Derived parameters | tHb, BE, HCO₃⁻, TCO₂, sO₂, anion gap, corrected Ca²⁺ |
| Sample Types | Arterial, venous and capillary blood |
| Calibration | Fully automatic liquid calibration |
| Operating Conditions | Temperature: 15 to 30°C Humidity: 15 to 80% RH |
| User Interface | Graphical interface with intuitive navigation |
| Data Storage | Up to 50,000 results with patient ID, date, and time |
| Data Connectivity | RS232, USB, LIS via HL7 protocol |
| Barcode Scanner | Integrated CCD barcode scanner (1D & 2D barcodes) |
| Quality Control | Multi-level QC with Levey-Jennings charting |
| Printer Support | External laser printer compatibility |
| Power Supply | 100 to 240V AC, 50/60Hz |
| Power Consumption | Less than or equal to 100 W |
| Dimensions | Approx. 370 × 360 × 450 mm |
| Weight | Approx. 15 kg |
Features
High-Resolution Touchscreen Interface
Multi-Parameter Analysis
Automated Calibration System
Integrated multi-level QC
Rapid Start-Up and Standby Mode
Automated Sample Aspiration
Flexible Testing Modes
Ultra-Fast Analysis Time
Multi-Sample Mode Compatibility
Cloud-Ready Data Integration
Seamless LIS/HIS Integration
Pre-Packaged Reagent Cartridges
Automatic Reagent Recognition
Multi-Mode Connectivity
Standard Accessories
Accessories | Quantity |
Main unit of the analyzer (AC 100 to 240V) | 1 |
pCO2/PO2 integrated electrode | 1 |
TH/HCT integrated electrode | 1 |
Ref electrode | 1 |
pH electrode | 1 |
Glu/Lac unit | 1 |
K electrode | 1 |
Na electrode | 1 |
Cl electrode | 1 |
Ca electrode | 1 |
User manual | 1 |
LAC/GLU Electrode | 1 |
Optional Accessories
| PCO2/PCO2 integrated Electrode (6 months warranty) | 1 |
| TH/HCT integrated electrode | 1 |
| Ref electrode | 1 |
| pH electrode | 1 |
| K electrode | 1 |
| Na electrode | 1 |
| Cl electrode | 1 |
| Ca electrode | 1 |
| Lac/GLU integrated Electrode | 1 |
| Ion Electrode Sealing Ring (Silicon rubber φ2.6 × 1.9 mm) | 1 |
| pCO2, pO2 electrode sealing ring (Silicon rubber φ2.8 × 2.0 mm) | 1 |
| Needle for blockage elimination (φ 0.6 × 160mm) | 1 |
| Auxiliary pump tube for Blood Gas (BPT, 1.6 × 4.8 × 3） | 1 |
| Tektronix Tube (φ 2.5 × 0.8 × 120 mm) only for probe | 1 |
| Tektronix Tube (φ 2.74 × 1.02 × 200 mm) only for pump | 1 |
| Printer paper (φ 50 × 80 mm) | 1 |
| Needle wiper | 1 |
| Resistive touch pen (0.5 × 150mm) | 1 |
| Maintenance electrode A | 1 |
| Maintenance electrode B | 1 |
| Ion Dummy electrode (optional) | 1 |
| O’ ring (2.6 × 1.9 mm) | 1 |
| Power cord | 1 |
| Fuse | 1 |
| Quality control (H:2ml × 10+ M:2ml × 10 + L:2ml × 10 per pack) | 1 |
| Quality control (H:2ml × 30 or M:2ml × 30, or L: 2ml × 30 per pack) | 1 |
| Blood Gas Reagent Pack (50 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (75 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (100 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (150 tests per pack with 46 days validity) | 1 |
| Blood Gas Reagent Pack (200 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (300 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (400 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (500 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (50 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (75 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (100 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (150 tests per pack with 46 days validity) | 1 |
| Blood Gas Reagent Pack (200 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (300 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (400 tests per pack with 45 days validity) | 1 |
| Blood Gas Reagent Pack (500 tests per pack with 45 days validity) | 1 |
| Flush solutions （without GLU/LAC） | 1 |
| Flush solutions （with GLU/LAC） | 1 |
| Refill solution for ISE electrodes (K/Na/Cl/Ca/pH, 0.8ml × 5 pieces) | 1 |
| Refill solution for Ref electrode (20ml × 1piece) | 1 |
| Refill solution for pO2 electrode （1 PCS） | 1 |
| Refill solution for pCO2 electrode （1 PCS） | 1 |
| Multi-Enzyme Deproteinizer | 1 |
Applications
Blood Gas and pH Analyzer MD-BGP-1002 supports the diagnosis and management of respiratory failure, ARDS, COPD, sepsis, diabetic ketoacidosis, cardiac and renal disorders, metabolic imbalances, shock, poisoning, and neuromuscular diseases.
Medical Deals' Blood Gas and pH Analyzers are designed to deliver rapid and precise analysis of blood gases, electrolytes, and metabolites. Their advanced microfluidic system optimizes reagent usage, reducing operational costs while maintaining superior analytical performance. They feature an intuitive, high-resolution touchscreen that offers a seamless user experience with an intelligent navigation system for streamlined operation. Our product embodies excellence in medical diagnostics, reinforcing its reputation as a trusted solution for healthcare institutions.
